Battery pack

LP503035 3.7v 503035 li polymer battery 500mah

503035 ultra thin small 3.7v 500mah lipo battery lp 503035 053035 3.7v 500mah li-ion polymer battery specification:

Brand	Junda battery
Model	J-503035PL
Nominal Voltage	3.7V
Nominal Capacity	500mAh
Standard charge rate	0.2C - 1.0C(max)
Standard discharge rate	0.5C - 2.0C(max)
Working Efficiency	≥99%
Operating Voltage Range	3.7V-4.2V
Over-charge Protection Voltage	4.2V
Over-discharge Protection Voltage	2.75V or 3V
Cycle Life	above 800 cycles
Battery Dimension (mm)	5.0mm30mm35mm
Battery Weight	about 8g
Charge Temperature	0°C~45°C
Discharge Temperature	-20°C~60°C
Storage Temperature	-20°C~45°C
Battery color	blue PVC film or silver grey
Storage Performance	80% power remains for one year
