7.4v li-ion battery pack 18650 2600mAh

7.4v li-ion battery pack 18650 2600mAh Specification:

Model :EST-ICR18650 2S1P

Voltage(V):7.4

Capacity(mAh) :2200

Internal Impedance(MΩ): ≤250

Over-Charge detect voltage(V )：  4.25±0.025V

Over-discharge detect voltage(V )：  3.0±0.1V

Standard discharge current(C): 0.2

Maximum discharge current(C):1

Charge temperature range (°C): 0 ~ 45

Discharge temperature range (°C): -20 ~ 60

Dimension(mm)：22*37.5*71(Max)

Lead model: JST ELP-02V-2P negative female/male plug UL1007/18#, length: 95mm

Build in PCM

Features:

High energy density.

Excellent safety performance

Excellent storage performance and low self-discharge rate

Wide temperature range, operation from :-20°C~+60°C

Environmentally

Application:

Portable equipment: POS, Portable printer, handset.

Medical instrument: B ultrasound, Ecg monitoring instrument

Military equipment: IR telescope

Consumer electronics:PDA,MID,laptop,emergency light power source

power tool  e-bicycle

Industrial and commercial instrument: light power meter, Gas testing instruments, fusion splicer, flaw detector

Electric toy:RC car/ boat/helicopter

Cautions in use

(1)Handling

• Do not expose to, dispose of the battery in fire.
• Do not put the battery in a charger or equipment with wrong terminals connected.
• Avoid shorting the battery
• Avoid excessive physical shock or vibration.
• Do not disassemble or deform the battery.
• Do not immerse in water.
• Do not use the battery mixed with other different make, type, or model batteries.

(2)charge and discharge

• Battery must be charged in appropriate charger only.
• Never use a modified or damaged charger.
• Do not leave battery in charger over 24 hours.

(3) storage

• Store the battery in a cool, dry and well-ventilated area.

(4)disposal

• Regulations vary for different countries.  Dispose of in accordance with local regulations.
