Single cell rechargeble lithium ion battery cell Features:
No memory effect。
Long storage life。
Light weight and high energy density。
Longer service life, 1C for Circulation using 500 charge/discharge Cycle, Capacity above 80%。
Applications:
Electronic Cigarette。
RC Applications, car, plane etc.
Safety, Alarm, Electric meter, power backup etc.、
Building portable power device that needs high energy density and low weight, Petroleum drill。
Details Li-ion rechargeable battery cell:
Cylindrical Li-ion Batteries | ||||||
Model | Nominal Voltage | Capacity | Dimension | Weight | ||
(V) | Approx | |||||
Typical | Nominal | Diameter | Height | (g) | ||
(mAh) | (mAh) | (mm) | (mm) | |||
ICR14430 | 3.7 | 650 | 620 | 14.3 | 43.0 | 16 |
ICR14470 | 3.7 | 720 | 700 | 14.3 | 47.0 | 17 |
ICR14500 | 3.7 | 750 | 720 | 14.3 | 50.0 | 18 |
ICR14650 | 3.7 | 1050 | 1000 | 14.3 | 65.0 | 24 |
ICR17335 | 3.7 | 700 | 650 | 17.0 | 34.5 | 18 |
ICR17500 | 3.7 | 1100 | 1050 | 17.0 | 50.0 | 27 |
ICR17670 | 3.7 | 1500 | 1450 | 17.0 | 67.0 | 36 |
ICR18490 | 3.7 | 1400 | 1350 | 18.3 | 49.0 | 33 |
ICR18500 | 3.7 | 1500 | 1450 | 18.3 | 50 | 95 |
ICR18650 | 3.7 | 2000 | 1950 | 18.3 | 65.0 | 45 |
ICR18650 | 3.7 | 2200 | 2100 | 18.3 | 65.0 | 48 |
ICR18650 | 3.7 | 2400 | 2300 | 18.3 | 65.0 | 49 |
ICR18650 | 3.7 | 2600 | 2550 | 18.3 | 65.0 | 50 |
ICR18650 | 3.7 | 2800 | 2650 | 18.3 | 65.0 | 55 |
ICR26650 | 3.7 | 3000 | 2900 | 26.3 | 65 | 95 |
Cylindrical Li-ion High Drain Batteries | ||||||
Model | Nominal | Capacity | Dimension(max) | Weight Approx | ||
Voltage | (g) | |||||
(V) | Typical | Nominal | Diameter | Height | ||
(mAh) | (mAh) | (mm) | (mm) | |||
ICR18659D | 3.7 | 1400 | 1300 | 18.3 | 65.0 | 44.5 |
ICR26650D | 3.7v | 3000 | 2900 | 26 | 65 | 95 |
